Support full charging standard customization OEM/ODM
Technical Information
| Model | EVST-60/80/90/120/150/180/200/240-38-3-S-EU/US/GB/CDM |
Power Specification
| Rated power | 60kW / 80kW / 90kW / 120kW / 150kW / 180kW / 200kW / 240kW |
| Output voltage | 200–750V (200–1000V optional) |
| Output current | 0–200A / 250A / 0–250A |
Input Parameters
| Input voltage | AC380V ±20% / AC480V ±20% (optional) |
| Input current | 95A / 134A / 174A / 200A / 230A / 285A / 335A / 400A |
| Frequency | 50–60Hz |
Charging & Interface
| Gun quantity | 2 |
| Charging way | Quick or slow charge automatic switch |
| Charging mode | Swipe card / APP / Manual |
| Interface | 7-inch color touchscreen + IC contactless card reader |
| Cable length | 5m |
Communication
| Network connection |
Standard: CAN / RS485 / Ethernet Optional: GPRS / 4G / WiFi |
Mechanical
| Size (mm) | 1750 × 620 × 780 |
| Weight | 120kg |
| Input line length | OEM (Customization acceptable) |
| Gun cable length | 5m (Customization acceptable) |
Environmental
| Operating temperature | -25°C ~ +50°C (Derating above 50°C) |
| Operating humidity | 5%–90% RH, non-condensing |
| Altitude | ≤ 2000m |
| IP level | IP54 |
Standards & Protocols
| Standards | GB/T 20234 / EN 62196 / EN 61851-1 / JEVSG 105 / CHAdeMO |
| Protocols | GBT 27930 / CHAdeMO 2.0 / DIN 70121 / OCPP 1.6 (JSON) / ISO 15118 |
