Support full charging standard customization OEM/ODM
Hanging
Column
Technical Information
| Model | EVSD-D-7/15/20/30/40-22/33-1/3-W-EU/US/GB/CDM |
Power Specification
| Rated power | 7kW / 15kW / 20kW / 30kW / 40kW |
| Output voltage | 200–750V / 200–1000V |
| Output current | 20A / 37A / 50A / 100A / 133A |
Input Parameters
| Input voltage | 90–265V / 260–475V (480V 3-phase optional) |
| Input current | 23A / 30A / 32A / 45A / 64A |
| Power factor | > 0.99 |
| Work efficiency | ≥ 95% |
Display & Interface
| Operating interface | 4.3-inch color LCD display |
| Networking mode | WiFi / Bluetooth / 4G / LAN |
| Networking protocol | OCPP 1.6J / OCPP 2.0 |
Mechanical
| Size (mm) | 545×380×170 / 645×454×170 / 721×475×232 |
| Weight | 20kg / 30kg / 35kg / 45kg / 64kg |
| Input line length | 5m (Customization acceptable) |
| Gun cable length | OEM (Customization acceptable) |
Environmental
| Auxiliary source | 12V (24V optional) |
| IP level | IP54 |
| Operating temperature | -25°C ~ +50°C (Derating above 50°C) |
| Working humidity | 5%–90% RH, no condensation |
| Altitude | ≤ 2000m |
Standards & Protocols
| Standards | GB/T 20234 / EN 62196 / EN 61851-1 / JEVSG 105 / CHAdeMO |
| Communication protocol | GBT 27930 / CHAdeMO 2.0 / DIN 70121 / ISO 15118 |
Powering Qatar’s EV Future – Are You Ready?
Powering Qatar’s EV Future
WATT EV is rapidly expanding its charging network across Qatar, bringing reliable and accessible stations to highways, commercial hubs, residential areas, and key public locations.
As the nation moves toward cleaner mobility, WATT EV ensures drivers have fast, secure, and convenient charging wherever they go. From home chargers to high-performance public stations, we’re powering Qatar’s electric future with innovation and dependability.
