Product Specifications

Charging Interface

• Connector Type: Mennekes Type 2

Power & Electrical

• Power Phase: AC 400V, 50/60Hz (Three Phase)

Power Output

• D011WX4-03: 11 kW

• D022WX4-03: 22 kW

Electric Current

• D011WX4-03: 16A

• D022WX4-03: 32A

• Adjustable Current: Freely adjustable via APP

Cable & Connection

• Power Connector: Power cord with open wiring
• Cable Length: 5 meters (customizable)

Size & Packaging

• Product Size: 355 × 250 × 93 mm
• Packing Size: 540 × 320 × 250 mm

Weight

• Net Weight: 8 kg / 8.3 kg

• Gross Weight: 9 kg / 9.6 kg

Display & Smart Features

• Display: 4.3-inch LCD screen + LED indicator
• Language: English (customizable)
• Connectivity: APP (Wi-Fi + Bluetooth), OCPP (Ethernet + 4G), RFID
• Dynamic Load Balancing (DLB): Optional
• Charging Schedule: Off-peak charging via APP or panel buttons

Working Environment

• Operating Temperature: -25°C to +55°C
• Ambient Humidity: 0–95% RH
• Installation Altitude: < 2000 m
• Protection Rating: IP65

Safety & Certification

• Fire Rating: V0
• Safety Protections:
Overvoltage, Overcurrent, Low-voltage, ESD, Lightning, Overcharge, Overload, Fire, Overheat, Waterproof, Leakage & Chip Protection
• Certifications: CE, EMC, ROHS, FCC
