12V 100Ah Lithium Power Pack

Grade A LFP(lithium iron phosphate) cells to ensure safety and performance

12V 100Ah Lithium Power Pack

The Watt 12V 100Ah Lithium Power Pack is a compact, reliable, and high-performance energy solution designed for mobility, outdoor use, and light-duty power applications. Built with advanced lithium iron phosphate (LFP) cells, it delivers stable power output, enhanced safety, and long service life, making it a smart upgrade over traditional lead-acid batteries.

Ideal for golf carts, RVs, caravans, marine systems, camping setups, and portable power needs, this power pack ensures consistent performance even in demanding conditions. Its lightweight design makes installation and handling easy, while the integrated Battery Management System (BMS) protects against overcharging, over-discharging, overheating, and short circuits.

With fast charging capability and high energy efficiency, the Watt 12V 100Ah Lithium Power Pack supports longer runtimes and reduced maintenance. It is engineered for users who need dependable power, longer cycle life, and space-saving energy storage without compromising safety or performance.

General Specifications
Battery TypeLithium Iron Phosphate (LiFePO₄)
Nominal Voltage12.8V DC
Rated Capacity100Ah
Nominal Energy1.28 kWh
Cell Configuration4S1P
Usable Depth of Discharge (DoD)Up to 80%
Cycle Life≥ 6,500 Cycles
Electrical Parameters
Maximum Charge Voltage14.6V
Cut-off Voltage10V
Maximum Discharge Current100A
Standard Charge Current20A (0.2C)
Round-Trip Efficiency≥ 98%
Physical Specifications
Dimensions (L × W × H)330 × 172 × 214 mm
WeightApprox. 10.5 kg
Mounting OptionsFloor or Wall Mount
Ingress ProtectionIP65
Environmental Conditions
Charging Temperature0°C to 45°C
Discharging Temperature-20°C to 55°C
Storage Temperature0°C to 35°C
Humidity Range5% – 95% (Non-condensing)
Protection & Safety
Battery Management System Built-in BMS with comprehensive protection
Protection Features Over-charge, Over-discharge, Over-current,
Over-temperature, Short circuit
Design & Reliability
Design Life≥ 15 Years
MaintenanceLow maintenance, no watering required
Eco-FriendlyFree from lead and heavy metals
