12V LiFeP04 LITHIUM Battery AN-LFP
12V LiFeP04 LITHIUM Battery AN-LFP
This 12V LiFePO4 Lithium Battery offers a durable and efficient energy solution, ideal for a variety of applications requiring stable power storage. It combines high capacity, superior safety, and longer lifespan, ensuring reliable performance for both residential and commercial use.
features
Longer Cycle Life: Offers up to 20 times longer cycle life and 5 times longer calendar life than traditional lead-acid batteries, significantly reducing the total cost of ownership.
Higher Power: Delivers twice the power of lead-acid batteries while maintaining high energy capacity, making it ideal for demanding applications.
Lightweight: Weighs approximately 3% of the weight of comparable lead-acid batteries, making it easier to handle and install.
Wide Temperature Range: Operates efficiently within a temperature range of -20°C to 40°C, ensuring reliability in varied environmental conditions.
Superior Safety: Uses Lithium Iron Phosphate (LiFePO4) chemistry, minimizing the risk of explosion or combustion from overcharging or short-circuit situations.
Environmentally Friendly: The battery is free from harmful heavy metals and designed for a sustainable lifecycle.
| Battery Type | LiFePO4 | |||
|---|---|---|---|---|
| Typical Capacity (Ah) | 100Ah | 200Ah | 300Ah | 100Ah |
| Typical Voltage (V) | 12.8V | 12.8V | 12.8V | 25.6V |
| Energy Storage | 1280Wh | 2560Wh | 3840Wh | 2560Wh |
| Working Temperature (°C) |
Charge: 0–55°C Discharge: -20–60°C |
|||
| Storage Temperature (°C) | -20–40°C | |||
| Max Charge Current (A) | 100A | 200A | 200A | 100A |
| Recommended Charge Current (A) | 50A | 100A | 100A | 50A |
| Max Discharge Current (A) | 100A | 200A | 200A | 100A |
| SOC Accuracy | <8% | |||
| Dimensions (mm) | 340 × 185 × 219 | 522 × 242 × 223 | 522 × 242 × 223 | 522 × 242 × 223 |
| Weight (kg) | 10 kg | 26 kg | 25.6 kg | 25.6 kg |
| IP Grade | IP54 | |||
| Certifications | CE, ROHS, UN38.3, MSDS | |||
