Hybrid Solar Inverter (Evo Series)
Hybrid Solar Inverter (Evo Series)
The EVO Series Hybrid Solar Inverters (AN-SCI-EVO Series) offer an efficient, reliable, and versatile solution for both off-grid and grid-tied solar systems. With power ratings up to 6500W, these inverters come equipped with advanced features, including a built-in MPPT solar controller, dual output, and high PV input voltage range. The inverters are perfect for residential, commercial, and industrial applications, offering energy independence while ensuring efficient battery charging and power conversion.
Max. Efficiency 98%
40A MPPT
IP21 Ingrees Protection
Features of Module
Pure Sine Wave Inverter: Provides stable and clean power for sensitive equipment.
Built-in 120A MPPT Solar Controller: Maximizes energy harvest from your solar panels and efficiently charges the batteries.
Dual Output: Can handle two load outputs simultaneously, optimizing energy distribution.
High PV Input Voltage Range: Supports solar panels with a voltage range from 60-450VDC (depending on the model), offering flexibility in system design.
Smart Battery Charging: The inverter features a smart battery charging design to extend battery life and optimize performance.
Wi-Fi Enabled: Allows for remote monitoring and control via mobile apps for iOS and Android.
Anti-Dust Kit: Built-in protection for harsh environments ensures longer lifespan and reliable performance.
| Model | AN-SCI-EVO-4200 | AN-SCI-EVO-6200 |
|---|---|---|
| RATED POWER | ||
| Maximum PV Input Power | 4200W | 6200W |
| GRID-TIE OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage / Maximum DC Voltage | 360VDC / 500VDC | |
| Start-up Voltage / Initial Feeding Voltage | 90VDC / 120VDC | |
| Maximum DC Voltage | 60–450VDC | |
| Number of MPPT Trackers / Maximum Input Current | 18A | 22A |
| GRID OUTPUT (AC) | ||
| Nominal Output Voltage | 220 / 230 / 240VAC | |
| Output Voltage Range | 195.5 – 253VAC | |
| Nominal Output Current | 18.2A | 27.0A |
| Power Factor | >0.99 | |
| Feed-in Grid Frequency Range | 49–51±1Hz / 59–61±1Hz | |
| EFFICIENCY | ||
| Maximum Conversion Efficiency (Solar to AC) | 98% | |
| TWO-LOAD OUTPUT POWER | ||
| Full Load | 4200W | 6200W |
| Maximum Main Load | 4200W | 6200W |
| Maximum Second Load (Battery Mode) | 1400W | 2067W |
| Main Load Cut-Off Voltage | 22VDC | 44VDC |
| Main Load Return Voltage | 26VDC | 52VDC |
| OFF-GRID OPERATION | ||
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 120–140VAC / 180VAC | |
| Acceptable Input Voltage Range | 90–280VAC or 170–280VAC | |
| Maximum AC Input Current | 30A | 40A |
| Nominal Operating Frequency | 50 / 60Hz | |
| Surge Power | 8400W | 12400W |
| BATTERY MODE OUTPUT (AC) | ||
| Nominal Output Voltage | 220 / 230 / 240VAC | |
| Output Waveform | Pure Sine Wave | |
| Efficiency (DC to AC) | 94% | |
| BATTERY & CHARGER | ||
| Nominal DC Voltage | 24VDC | 48VDC |
| Maximum Charging Current (Solar to AC) | 120A | |
| Maximum AC Charging Current | 100A | |
| GENERAL PHYSICAL | ||
| Dimension (D × W × H) mm | 420 × 350 × 110 | 450 × 350 × 110 |
| Net Weight (kg) | 9 | 10 |
| INTERFACE | ||
| Communication Interface | WIFI | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10°C to 50°C | |
| Storage Temperature | -15°C to 60°C | |
