LiFePO4 Lithium Battery Pack AN-LPB-Npro
LiFePO4 Lithium Battery Pack AN-LPB-Npro
The NPro LiFePO4 Battery Pack is designed for long-term, high-efficiency energy storage solutions. With its modular design and compact size, it offers flexibility in various applications, from residential to commercial use. It is engineered with advanced technology for maximum battery life and optimized charging, ensuring safe, efficient, and reliable performance.
features
Long Service Life: Provides over 8 years of service life, offering dependable performance for a wide range of energy storage needs.
Modular Design: Compact, lightweight, and easy to install with front operations, making maintenance and upgrades hassle-free.
1C Charging & 1.5C Discharging: Supports fast charging and discharging, providing energy storage without delays.
LCD Touch Screen: Features a touch screen design that allows easy monitoring and control, ensuring smooth operation.
Energy Consumption Management: Efficient energy management system for maximizing battery lifespan and system performance.
Automatic Parallel Machines: Multiple units can be connected automatically without manual operation, expanding capacity as required.
Robust Communication: Equipped with RS485, RS232, and CAN interfaces, offering seamless integration with the energy storage inverter.
Safety Certifications: Certified with CE, ROHS, UN38.3, and MSDS for safe and compliant use.
IP54 Protection: Protected against dust and water, ensuring reliability in harsh environments.
Temperature Range: Operates in temperatures between -20°C and +55°C, with discharge tolerance up to -60°C.
High-Performance Components: Built with international-brand devices to ensure the highest reliability and performance.
–Cover
–Hanging Ear
–Handle
–Output Terminal
–Display Screen
–Cooling Case
–Communication Interface
–Reset Switch
–Status lamp
| Battery Type | LiFePO4 | |||
|---|---|---|---|---|
| Typical Capacity | 200Ah | 100Ah | 200Ah | 314Ah |
| Typical Voltage | 25.6V | 51.2V | 51.2V | 51.2V |
| Energy Storage | 5 kWh | 5 kWh | 10 kWh | 16 kWh |
| Voltage Working Range | 22.4–29.2V | 44.8–58.4V | 44.8–58.4V | 44.8–58.4V |
| Working Temperature (°C) |
Charge: 0–55°C Discharge: -20–60°C |
|||
| Storage Temperature (°C) | -20–40°C | |||
| Standard Charge Current | 0.5C | |||
| Max Charge Current | 200A | 100A | 200A | 200A |
| Recommended Charge Current | 100A | 50A | 100A | 150A |
| Max Discharge Current | 200A | |||
| SOC Accuracy | <8% | |||
| Cycle Life | 6000 Cycles | 10000 Cycles | ||
| Dimensions (mm) | 485 × 475 × 180 | 485 × 475 × 180 | 796 × 485 × 180 | 800 × 380 × 250 |
| IP Grade | IP54 | |||
| Cooling Method | Natural | |||
| Communication Mode | RS232, CAN, RS485 | |||
| Certification | CE, ROHS, UN38.3, MSDS | |||
