MPPT Solar Inverter 6500W/12000W
The FGI-S6500W and FGI-S12000W MPPT Solar Inverters are designed to deliver high-efficiency, reliable, and cost-effective solar power solutions. These inverters support a wide range of applications with their ability to operate in both residential and commercial settings. With maximum power outputs of 6500W and 12000W respectively, they provide seamless energy conversion for solar systems of various scales.
features
Pure Sine Wave Output: Ensures smooth and stable power supply for sensitive devices.
Wide PV Input Voltage Range: 60-450V DC, suitable for varying solar panel setups.
Built-in MPPT Solar Controller: Maximizes solar energy efficiency and optimizes battery charging.
Lithium Battery Compatibility: Supports automatic activation of lithium batteries via AC and PV.
Overload Protection: Provides safety with integrated protections against overload and short circuit.
Smart Battery Charging: Designed to maximize battery lifespan with intelligent charging.
Wi-Fi Remote Monitoring: Optional Wi-Fi connectivity for remote monitoring and management.
RGB Lights: Visual indicators to easily identify inverter status.
Dust Proof and Weatherproof: Built for harsh environments with IP21 protection.
| Item | 6500W | 12000W |
|---|---|---|
| RATED POWER | 6500W | 12000W |
| Phase | 1-phase in / 1-phase out | |
| Maximum PV Input Power | 9000W | 15000W |
| AC INPUT | ||
| Acceptable Input Voltage Range | 90-280 VAC | |
| Frequency Range | 50 Hz / 60 Hz (Auto sensing) | |
| Rated Input Voltage | 220 / 230 / 240VAC | |
| AC OUTPUT | ||
| Nominal Output Voltage | 220 / 230 / 240VAC | |
| Power Factor | 1PF | |
| Surge Power | 12kVA | 24kVA |
| Switch Time (ms) | 10 (APP/UPS mode) / 20 (GEN mode) | |
| Wave Form | Pure Sine Wave | |
| Maximum Efficiency (Battery Mode) | 94% (48V) | |
| PV / AC CHARGER | ||
| MPPT Voltage Range | 60-450Vdc | |
| Number of MPP Trackers / Maximum Input Current | 1 / 27A | 2 / 22.5A |
| Maximum PV Charge Current | 120A | 160A |
| Maximum AC Charge Current | 120A | 160A |
| Max. Charge Current (PV + AC) | 160A | |
| Max PV Open Circuit Voltage | 500VDC | |
| PV Start-up Voltage | 80Vdc | |
| BATTERY | ||
| Normal Voltage | 48VDC | |
| Battery Type | Lithium and Lead-acid | |
| PHYSICAL | ||
| Dimension (D × W × H) mm | 440 × 355 × 117 | 527 × 435 × 138 |
| Net Weight (kg) | 8.4 | 14.5 |
| GENERAL DATA | ||
| HMI | LCD | |
| Communication Port | RS485 / CAN / RS232 | |
| Monitoring | WiFi (Optional) | |
| IP Degree | IP21 | |
| Humidity | 5% to 95% (Non-condensing) | |
| Operating Temperature | -10°C ~ 60°C | |
| Storage Temperature | -15°C ~ 60°C | |
| Max. Operating Altitude | 4000m (Derating above 1000m) | |
