Off-Grid Solar Inverter 3.6kW/6.2kW
Off-Grid Solar Inverter 3.6kW/6.2kw
The FGI-AS Series Off-Grid Solar Inverter provides reliable, clean, and stable power for residential and off-grid applications. It operates at both 12V and 24V and offers an impressive maximum output power of 4200W for the 3.6KW model and 6200W for the 6.2KW model. With built-in MPPT (Maximum Power Point Tracking) technology, it optimizes solar energy conversion to deliver efficient and sustainable power.
features
Dual-Voltage Operation: Supports 12VDC and 24VDC, providing flexibility for different energy needs.
Pure Sine Wave Output: Ensures smooth, clean power for sensitive devices like computers and home appliances.
Built-in MPPT Solar Charger: Maximizes solar power generation, ensuring optimal energy efficiency.
Lithium Battery Support: Compatible with lithium batteries for long-lasting, efficient storage.
Smart Battery Charging: Automatically adjusts charging to optimize battery health and lifespan.
Cold Start Function: Provides power even when there is no battery charge, ensuring reliable energy.
Wi-Fi/GPRS Connectivity: Allows remote monitoring for convenient system control and diagnostics.
RGB Lights: Visual indicators for inverter status, offering a user-friendly monitoring experience.
Overload and Short Circuit Protection: Safeguards the system by shutting down under extreme conditions.
| Item | Model 1 | Model 2 |
|---|---|---|
| Phase | 1-phase | |
| Maximum PV Input Power | 4200W | 6000W |
| Rated Output Power | 3600W / 3600VA (3000 / 3150 / 3300) | 6200W / 6200VA (5300 / 5500 / 5700) |
| Maximum Solar Charging Current | 120A | 100A |
| GRID-TIE OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage / Maximum DC Voltage | 360 / 500VDC | |
| Start-up Voltage / Initial Feeding Voltage | 60VDC / 90VDC | |
| MPPT Voltage Range | 60-450VDC | |
| Maximum Input Current | 1 / 18A | 1 / 22A |
| GRID OUTPUT (AC) | ||
| Nominal Output Voltage | 120VAC (100 / 105 / 115V settable) | |
| Output Voltage Range | 90-150VAC | |
| Nominal Output Current | 30A | 51.5A |
| Power Factor | >0.99 | |
| EFFICIENCY | ||
| Maximum Conversion Efficiency (DC / AC) | 98% | |
| TWO LOAD OUTPUT POWER (DC / AC) | ||
| Full Load | 3600W | 6200W |
| Maximum Main Load | 3600W | 6200W |
| Maximum Second Load (Battery Mode) | 1200W | 2067W |
| Maximum Load Cut-off Voltage | 26VDC | 52VDC |
| Maximum Load Return Voltage | 27VDC | 54VDC |
| OFF-GRID OPERATION | ||
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 110VAC / 120VAC | |
| Acceptable Input Voltage Range | 90-145VAC ±2% | |
| Frequency Range | 49-51 ±1Hz | |
| Maximum AC Input Current | 40A | 80A |
| BATTERY MODE OUTPUT (AC) | ||
| Nominal Output Voltage | 120VAC (100 / 105 / 115V settable) | |
| Output Waveform | Pure Sine Wave | |
| Efficiency (DC to AC) | 94% | |
| BATTERY & CHARGER | ||
| Nominal DC Voltage | 24VDC | 48VDC |
| Maximum Solar Charging Current | 120A | 120A |
| Maximum AC Charging Current | 100A | 100A |
| Maximum Solar + AC Charging Current | 120A | 120A |
| PHYSICAL | ||
| Dimension (D × W × H) mm | 420 × 350 × 110 | |
| Carton Dimension (D × W × H) mm | 500 × 415 × 180 | |
| Net Weight (kgs) | 8.8 | 9.5 |
| Gross Weight (kgs) | 10 | 11.5 |
| INTERFACE | ||
| Communication Port | RS232 / RS485 / WiFi / GPRS / Lithium Battery | |
| ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10°C ~ 50°C | |
| STANDARD | ||
| Compliance Safety | CE | |
