On-Grid Solar Inverter
On-Grid Solar Inverter
AN -OGI 3KW/6KW/10KW/15KW
The OGI Series On-Grid Solar Inverters provide highly efficient and reliable solar power conversion for residential and commercial applications. With models ranging from 3kW to 15kW, these inverters are ideal for integrating solar systems with the grid. The OGI Series ensures seamless solar energy conversion with high efficiency and comes with a built-in LCD+LED display for real-time monitoring. They support a wide range of input voltages, making them compatible with various grid configurations, and are designed to operate in both residential and commercial environments.
features
Wide Voltage Range Compatibility: Works with various power grids and ensures flexibility in installation.
Off-Grid Functionality: Solar power with or without grid connection.
110% Power Oversizing: Can handle up to 200% peak output power to ensure maximum energy generation.
IP65 Protection: Perfect for outdoor installation in harsh weather conditions.
LCD+LED Display: Colorful, easy-to-read display with real-time monitoring.
Built-in PV Switch: Simplifies system control and enhances safety.
WiFi & GPRS Connectivity: Monitor and control remotely via iOS and Android applications.
Anti-Reverse Flow Protection: Safeguards against power loss from the grid.
| Input (DC) | |||||
| Max. input Power | 4.5KW | 9KW | 13.5KW | 18KW | |
| Max. input voltages | 500Vdc | ||||
| Start Voltage | 90Vdc | ||||
| Rated Input Voltage | 360Vdc | ||||
| MPPT Voltage Range | 60Vdc – 450Vdc | ||||
| Number of MPP Trackers | 1 | 2 | 3 | 4 | |
| Number of String per MPPT | 1 / 1 | 1 / 2 | 1 / 3 | 1 / 4 | |
| Max. Current per MPPT | 18A | 18A × 2 | 18A × 3 | 18A × 4 | |
| Max short Circuit Current per MPPT | 23A | ||||
| Output (AC) | |||||
| Rated Output Power | 3KW | 6KW | 10KW | 15KW | |
| Max. Output Power | 8KW | 12KW | 20KW | 30KW | |
| Max. Output Current | 13A | 26A | 43A | 65A | |
| Rated Grid Frequency | 50Hz / 60Hz | ||||
| Rated Grid Voltage | 220Vac / 230Vac / 240Vac | ||||
| Power Factor | >0.99 | ||||
| THDI | <3% | ||||
| Efficiency | |||||
| Max. Efficiency | 98% | ||||
| European Efficiency | 97% | ||||
| MPPT Efficiency | 99% | ||||
| Protection | |||||
| DC switch | Yes | ||||
| DC Reverse Polarity Protection | Yes | ||||
| Anti-islanding Protection | Yes | ||||
| AC short Circuit Protection | Yes | ||||
| Residual Current Monitoring Unit | Yes | ||||
| Insulation Resistance Monitoring | Yes | ||||
| Ground Fault Monitoring | Yes | ||||
| Grid Monitoring | Yes | ||||
| PV String Monitoring | Yes | ||||
| Surge Protection | Yes | ||||
| Communication | |||||
| Display | Color LCD + LED + APP | ||||
| Communication | RS485 / RS232 / Wi-Fi | ||||
| Standard Compliance | IEC 62109-1/2, IEC 61000-1/3 | ||||
| Certification | — | ||||
| General Data | |||||
| Dimensions (D×W×H) mm | 431×414.5×97 | 441×424.5×107 | 452×435.5×118 | 463×446.5×129 | |
| Weight (kgs) | 6 | 11.5 | 17.5 | 23.5 | |
| Operating Temperature Range | -10°C ~ 60°C | ||||
| Cooling Method | Fan / Smart Cooling | ||||
| Protection Degree | IP65 | ||||
| Max. Operating Altitude | 4000m | ||||
| Relative Humidity | 0 – 100% | ||||
| Topology | Transformerless | ||||
