Portable Solar Generator
Portable Solar Generator
The Portable Solar Generator from the AN-MPSG-N Series is designed for versatile, off-grid energy solutions. With multiple power options ranging from 500W to 5000W, this generator is perfect for residential, commercial, or outdoor applications. It features a built-in LiFePo4 lithium battery and a dual CPU intelligent control system for high efficiency and reliability.
features
Dual CPU Intelligent Control: Delivers advanced performance technology, improving energy management.
Built-In Lithium Battery: LiFePo4 technology for extended lifespan and higher energy storage.
Energy-Saving Modes: Flexible modes such as mains supply, energy-saving mode, and battery mode.
MPPT Controller: Maximizes charging efficiency, improving it by over 20%.
Overcharge & Overdischarge Protection: Ensures longer battery life and safety.
Efficient Cooling: Smart temperature control with an intelligent exhaust fan.
Flexible Power Output: Includes 5V DC USB output and 12V DC output ports, supporting various devices.
Short Circuit Protection: Built-in for safety, along with overall automatic protections and alarms.
Compact & Portable Design: Easy to transport for on-the-go energy needs.
| Rated Power | 500W | 1000W | 2000W | 3000W | 5000W |
|---|---|---|---|---|---|
| Battery Voltage | 12.8V | 25.6V | 25.6V | 25.6V | 48V |
| Built-in Lithium Capacity | 600Wh | 1200Wh | 2500Wh | 3000Wh | 5000Wh |
| Input Voltage Range | 110 / 220VAC ±10% | ||||
|---|---|---|---|---|---|
| Input Frequency | 45 – 65Hz | ||||
| Output Voltage | 110 / 120 / 220 / 240VAC (Optional) | ||||
| Output Frequency | 50Hz / 60Hz | ||||
| Output Waveform | Pure Sine Wave | ||||
| Max PV Power | 240W | 480W | 800W | 1500W | 3000W |
|---|---|---|---|---|---|
| Charging Voltage Range | 15–90VDC | 30–90VDC | 30–90VDC | 30–130VDC | 60–160VDC |
| Rated Charge Current | 20A | 30A | 60A | — | — |
| USB Output | 5VDC (2 Ports, Max 2A) | ||||
|---|---|---|---|---|---|
| 12V DC Output | Available | ||||
| Communication | RS485 / WiFi (Optional) | ||||
| Transfer Time | Typical 5–8ms (Including detection time) | ||||
|---|---|---|---|---|---|
| Cooling | Intelligent temperature-controlled exhaust fan | ||||
| Display | Digital LCD | ||||
| Electricity Charging | Yes | ||||
| Operating Temperature | -10°C to +50°C | ||||
| Operating Humidity | 10% – 90% | ||||
| Protection | Software short-circuit protection | ||||
| External Size (mm) | 410×210×300 | 410×210×385 | 460×275×495 | 458×258×433 | 495×290×640 |
|---|---|---|---|---|---|
| Package Size (mm) | 458×258×348 | 460×275×495 | 550×300×600 | 495×290×640 | 585×315×760 |
| Net Weight | 18kg | 27kg | 50kg | 59kg | 90kg |
