Single Phase Hybrid Inverter
Single Phase Hybrid Inverter
AN-HYI 6KW/8KW/10KW/12KW
The HYI Series Single Phase Hybrid Inverters are designed to provide efficient, reliable, and flexible energy solutions for both residential and commercial applications. With a wide range of models (6kW, 8kW, 10kW, 12kW), the HYI series offers dual outputs, allowing smart load management and the integration of solar power with backup grid energy. Perfect for use in off-grid, grid-tied, or hybrid modes, these inverters come with built-in MPPT, ensuring optimal solar power generation efficiency and enabling seamless power switching between the grid and solar systems.
features
Pure Sine Wave Inverter: Provides stable and clean energy ideal for sensitive electrical devices.
IP65 Waterproof & Dustproof: Suitable for outdoor installations and harsh environmental conditions.
Dual Output: Supports multiple energy sources with smart load management.
User-Adjustable Charging Current & Voltage: Customizable settings to suit specific needs.
Built-in Communication Port (BMS/RS485): Enables system monitoring and control.
Efficient Maximum Power Point Tracking (MPPT): Ensures the most efficient use of solar power, maximizing energy harvest.
Programmable Operation Modes: Includes Grid-tie, Off-grid, and Hybrid with Backup modes.
Up to 6 Units Parallel Operation: Scalable solution for larger systems.
CT Function: Built-in current transformer (CT) for monitoring and optimizing energy use.
Touch LCD Display: Easy-to-use interface for operation and monitoring.
| Phase | 6KW | 8KW | 10KW | 12KW |
|---|---|---|---|---|
| Phase | 1-phase in / 1-phase out | |||
| Maximum PV Input Power | 9000W | 13500W | 16200W | 16200W |
| Rated Output Power | 6000W | 8000W | 10000W | 12000W |
| Maximum Charging Power | 6000W | 8000W | 10000W | 12000W |
| GRID-TIE OPERATION | ||||
| PV INPUT (DC) | ||||
| Maximum DC Voltage | 520Vdc | |||
| Start-up Voltage / Initial Feeding Voltage | 90Vdc / 120Vdc | |||
| MPPT Voltage Range | 50–500Vdc | |||
| Number of MPPT Trackers / Maximum Input Current | 2 / 18A | 2 / 18A + 36A | 2 / 18A + 36A | 2 / 18A + 36A |
| GRID OUTPUT (AC) | ||||
| Nominal Output Voltage | 220 / 230 / 240VAC | |||
| Output Voltage Range | 184–264.5VAC or 195.5–253VAC or 184–264.4VAC (Selectable) | |||
| Nominal Output Current | 26.1A | 34.8A | 43.5A | 52.2A |
| Power Factor | >0.99 | |||
| EFFICIENCY | ||||
| Maximum Conversion Efficiency (DC/AC) | 97% | |||
| OFF-GRID OPERATION | ||||
| AC INPUT | ||||
| AC Start-up Voltage / Auto Restart Voltage | 120–140VAC / 180VAC | |||
| Acceptable Input Voltage Range | 90–280VAC | |||
| Frequency Range | 50Hz / 60Hz (Auto sensing) | |||
| Maximum AC Input Current | 40A | 50A | 60A | 70A |
| BATTERY MODE OUTPUT (AC) | ||||
| Nominal Output Voltage | 220 / 230 / 240VAC | |||
| Output Waveform | Pure Sine Wave | |||
| Efficiency (DC to AC) | 93% | |||
| HYBRID OPERATION | ||||
| BATTERY & CHARGER | ||||
| Nominal DC Voltage | 48Vdc | |||
| Maximum Solar Charging Current | 135A | 190A | 220A | 250A |
| Maximum AC Charging Current | 135A | 190A | 220A | 250A |
| Maximum Charging Current | 135A | 190A | 220A | 250A |
| GENERAL PHYSICAL | ||||
| Dimension (D × W × H) mm | 521 × 470 × 236 | 600 × 483 × 260 | ||
| Net Weight (kg) | 27.5 | 38 | 42 | 45 |
| INTERFACE | ||||
| Parallel Function | Yes, 6 units | |||
| Communication Port | RS232 / RS485 / CAN / WiFi / Dry contact | |||
| ENVIRONMENT | ||||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||
| IP Degree | IP65 | |||
| Operating Temperature | -10°C ~ 50°C | |||
| Storage Temperature | -15°C ~ 60°C | |||
