EV DC Stationary DC+AC
DC charger with CCS 2 plug, GBT Plug and AC 44kW type 2 plug.
Input rating:400V 3ph 170A max.
Number of phase / wire:3ph / L1,L2,L3,N,PE
Output power: DC gun: 60Kw + AC43KW
Only one DC gun is available in a charging session. The AC charging gun is independent.
Output rating:200V-1000V DC + AC380V
Display:10” touch screen
Charging interface: DC1 ( CHAdeMO/GBT )/DC2
(CCS2) /AC1 (CCS2)
Network interface: Ethernet (standard); Wi-Fi, 4G(optional)
Open Charge Point Protocol: OCPP1.6
Ingress protection: IP54
Enclosure Protection against: IK10 according to IEC62262
Dimension (W*D*H)mm:700*750*1750mm
Certificate / Compliance: CE / EN 61851-1/-23
| Item Name | Item No | Power | Plugs | Commercial | Certificate |
|---|---|---|---|---|---|
| DC Charging station | HNDCXT-30 | 30kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
| DC Charging station | HNDCXT-40 | 40kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
| DC Charging station | HNDCXT-60 | 60kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
| DC Charging station | HNDCXT-90 | 90kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
| DC Charging station | HNDCXT-120 | 120kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
| DC Charging station | HNDCXT-180 | 180kW | CCS1/CCS2/GBT/CHAdeMo | 4G, WIFI, OCPP, TUV | CE |
